For a three-level distribution box, the grounding wire should typically be copper with a cross-sectional area of 6 mm² (or 10 AWG in the US), properly bonded to the cabinet and connected to a reliable earth point, ensuring a ground resistance below 25 ohms.

Ground Wire Material and Size

The grounding conductor should be copper, either bare or tinned, to ensure long-term conductivity and corrosion resistance. In most international standards, a 6 mm² copper wire is recommended, while in the US, a 10 AWG wire is commonly used for distribution boxes ( ). For connections between mounting plates and equipment like spindles, larger conductors such as 16 mm² copper or 6 AWG may be required depending on cable length and current paths to maintain low resistance ( ).

Installation and Bonding

• Cabinet Grounding: Attach the ground wire from a threaded stud at the bottom of the distribution box to the mounting plate.
• System Grounding: Connect a second wire from the mounting plate to the central grounding point of the facility ( ).
• Neutral Bonding: The neutral bus bar inside the LV cabinet should be bonded to the cabinet body through a copper link, typically 70 mm² in larger distribution systems ( ).
• Continuous Conductor: Ensure all ground connections are continuous and properly bonded to avoid potential differences between equipment parts ( ).

Ground Resistance Requirements

• The total ground resistance of the system should be less than 25 ohms for safety ( ).
• For critical equipment, the resistance between mounting plates and connected devices should be well below 0.1 ohm to ensure proper fault current dissipation ( ).
• If a single rod does not achieve the required resistance, multiple rods connected with a continuous conductor should be installed ( ).

Practical Considerations

• Use high-quality copper or copper-bonded steel rods to prevent corrosion and maintain long-term reliability ( ).
• Avoid double-tapping neutrals; each neutral should have a dedicated connection to the ground bar ( ).
• Test all installations after completion to verify resistance values and ensure compliance with safety standards ( ). By following these guidelines, a three-level distribution box can achieve safe, reliable grounding, protecting both equipment and personnel from electrical faults and surges.
