A cable management frame divided into upper and lower sections organizes and protects cables while facilitating maintenance and installation in network or FTTH setups.

Structure and Function

A cable management frame typically consists of two main sections: upper and lower brackets, which together form a complete management cabinet or enclosure . The upper section often serves as the entry point for incoming cables, guiding them into the frame while maintaining proper bend radius and preventing tangling. The lower section provides additional routing channels, supports outgoing cables, and can include features for securing or winding excess cable .

Mounting and Installation

These frames are designed to be mounted on walls, poles, or inside network cabinets. In FTTH networks, the frame can be attached to wooden poles using included screws, with the main part rotating on the pole bracket to facilitate cable winding . In network cabinets, the upper and lower sections may be integrated with cover-type, ring-type, or brush-type cable managers to protect cables from dust, reduce friction, and maintain a neat appearance .

Benefits of Upper and Lower Sections

• Organized routing: Separates incoming and outgoing cables, reducing clutter and tangling .
• Improved maintenance: The divided sections allow easier access for inspection, replacement, or re-routing of cables .
• Protection: Covers and brackets shield cables from dust, dirt, and accidental contact, enhancing safety and reliability .
• Flexibility: Rotating or adjustable frames accommodate different closure types and cable lengths, supporting both small and large installations .

Applications

• FTTH networks: Used at access points to manage fiber optic cables efficiently .
• Network cabinets and data centers: Supports horizontal and vertical cable management, ensuring proper bend radius and reducing strain on terminations .
• Telecom and enterprise environments: Provides structured cabling solutions for high-density setups, improving airflow and maintenance efficiency . In summary, a cable management frame divided into upper and lower sections enhances cable organization, protection, and accessibility, making it a critical component in both FTTH and network cabinet installations.
